エレベーター・エスカレーター
Elevator (Main specification)
Car No. | 1~3 | 4~6 | 7 | 8, 9 | 10 | 11 | 12, 13 | 14 | 15 |
---|---|---|---|---|---|---|---|---|---|
Use | Passenger | Passenger | Passenger | Passenger | Service | Service | Passenger | Service | Passenger |
Capacity (kg) | 1,600 | 1,600 | 1,600 | 1,600 | 2,400 | 2,000 | 1,600 | 1,250 | 900 |
Persons | 24 | 24 | 24 | 24 | 36 | 30 | 24 | 19 | 13 |
Speed (m/min) | 90 | 90 | 90 | 90 | 60 | 60 | 90 | 90 | 45 |
Units | 3 | 3 | 1 | 2 | 1 | 1 | 2 | 1 | 1 |
Stops | 8 (Front: 5, Back: 3) | 9 (Front: 8, Back: 1) | 11 (Front: 10, Back: 1) | 9 | 5 | 5 | 10 (Front: 9, Back: 1) | 11 (Front: 10, Back: 1) | 2 (Front: 1, Back: 1) |
Service Floor | Front: B3, B2, GL, 2, 3, Back: B1, 1, 4 | Front: B4, B2, B1, 1~5, Back: B3 | Front: B4~B1, 1~6, Back: GL | B4~B1, 1~5 | B1, 1~4 | B1, 1~4 | Front: B4~B1, 1~6, Back: B1 | Front: B4~B1, 1~6, Back: B1 | Front: GL, Back: 1 |
Notes | No. 1, 2: Handicapped | No. 4: Handicapped | Handicapped | Handicapped, Observation |
