エレベーター・エスカレーター
- 所在地：
- 愛媛県今治市
- 設計：
- KAJIMA DESIGN
Elevator (Main specification)
Year of Completion 2016 / Elevator 11 units
| Car No. | 1, 2 | 3, 4, 5 | 6, 7 | 8, 9 | 10, 11 |
|---|---|---|---|---|---|
| Use | Freight | Passenger | Service | Passenger | Passenger |
| Capacity (kg) | 1,500 | 1,600 | 1,600 | 1,450 | 1,450 |
| Persons | ー | 24 | 24 | 22 | 22 |
| Speed (m/min) | 45 | 45 | 45 | 45 | 45 |
| Units | 2 | 3 | 2 | 2 | 2 |
| Stops | 2 | 3 | 3 | 3 | 3 |
| Service Floor | 1-2 | 1-2, R | 6: 1-2, R 7: 1-2 |
1-2, R | 1-2, R |
| Notes | Handicapped | Handicapped | Handicapped | Handicapped |
Escalator (Main specification)
Year of Completion 2016 / Escalator 12 units
| Car No. | A1, B1 | A2, B2 | C1, D1 | E1, F1 | E2, F2 | G1, H1 |
|---|---|---|---|---|---|---|
| Type | S1000 | S1000 | S1000 | S1000 | S1000 | S1000 |
| Speed (m/min) | 30/20 | 30/20 | 30/20 | 30/20 | 30/20 | 30/20 |
| Service Floor | 1-2 | 2-R | 1-2 | 1-2 | 2-R | 1-2 |
| Rise (mm) | 5,800 | 6,060 | 5,800 | 5,800 | 6,060 | 5,800 |
| Angle | 30 | 30 | 30 | 30 | 30 | 30 |
| Units | 2 | 2 | 2 | 2 | 2 | 2 |
